This product is a specialized tool designed for pipe welding. It assists welders in quickly completing tack welding preparation. It is suitable for precisely aligning and connecting pipe-to-pipe, pipe-to-elbow, and pipe-to-flange joints, ensuring coaxial alignment of the connected pieces. This guarantees roundness, gap consistency, and concentricity of the pipe ends meet welding requirements, preventing misalignment or uneven gaps that can compromise weld quality.
|
Model |
Clamping Range |
Net Weight |
Dimension |
|
|
mm |
inch |
kg |
cm |
|
|
MI001 |
3-25.4 |
1/8”-1” |
0.6 |
8.5*6*3.5 |
|
MI020 |
9.53-50.8 |
3/8”-2” |
1.25 |
12.5*9.5*4.2 |
*Includes multiple adaptors as standard for various sizes. Customized solutions for special sizes are available; please specify your requirements when ordering.
This product is a mechanical pipe alignment device that utilizes high-strength adjusting bolts (jack bolts). By manually rotating these bolts, it generates powerful radial clamping force to restore pipe end roundness, align pipe sections, and secure the joint interface. Characterized by its simple structure, durability, reliability, and low cost, it achieves precise pipe end shaping, accurate positioning, and stable support. It provides the crucial foundation for obtaining high-quality circumferential weld seams, making it an essential tool for large-scale pipeline engineering projects.
This product is a specialized tool designed for pipe welding. It assists welders in quickly completing tack welding preparation. It is suitable for precisely aligning and connecting pipe-to-pipe, pipe-to-elbow, and pipe-to-flange joints, ensuring coaxial alignment of the connected pieces. This guarantees roundness, gap consistency, and concentricity of the pipe ends meet welding requirements, preventing misalignment or uneven gaps that can compromise weld quality.
This product is a specialized tool designed for pipe welding, assisting welders in tack welding preparation. It enables precise alignment for pipe-to-pipe, pipe-to-elbow, and pipe-to-flange connections by centering components along their axis. Ensures roundness, gap consistency, and coaxiality meet welding requirements while preventing misalignment or uneven gaps that compromise weld quality.
